Dual-Band Gateway

GTW-BL100

Category: Gateways

Engineered for reliability in the most demanding industrial environments, our 900MHz LoRa and Bluetooth® 5 dual-band gateway delivers unparalleled flexibility and performance. Combining the long-range, wall-penetrating power of LoRa with the energy-efficient, high-speed connectivity of Bluetooth® 5, this gateway ensures seamless communication across diverse conditions. Whether extending coverage deep into concrete structures or enabling efficient device connections in open spaces, it provides the right tool for every scenario-keeping your operations connected, resilient, and future-ready.

Brochure

Technical Specification

DC Input	7 VDC to 15 VDC
DC Input Jack	5.5mm OD, 2.5mm ID (+ive center pin)
Supply Current	65mA @ 12VDC
Power over Ethernet PoE	PoE, IEEE 802.3at, Mode A and B
USB	Limited to 5VDC and 0.5A

Operating Temperature	0°C to +75°C
Storage Temperature	-40°C to +85°C
Permissible Humidity	20 % to 85 % (Operation and Storage)
Protection Class	OVC 1
Pollution Degree	2
Ingress Protection	IP30

Temperature Measurement	-40ºC to +120ºC (±0.5ºC accuracy)
Humidity Measurement	0-100% RH (±3.5% accuracy)
Acceleration Measurement	6-axis accelerometer ±16g FSR

Housing Material	Flame Retardant Polycarbonate/ABS
Physical Dimensions	Height: 153 mm / 5.9 inches Width: 129 mm / 5.1 inches Depth: 40 mm / 1.6 inches
Weight	200g
Mounting	Wall mount (wall bracket) Desktop mount (rubber feet)

Edge Level Communication

Primary Sensor Communication

Transceiver	Bluetooth® 5 integrated transceiver
Frequency Band	2.4GHz
Communication Range	Up to 300m line of sight (Bluetooth® 5)
Data Rate	125kbps (Bluetooth® 5 long-range)
Protocol Type	Proprietary Bluetooth® 5 based
Output Power	Up to ±5dBm with temp. compensation
Receiver Sensitivity	-105dBm
Reporting Interval	User programmable

Range Extender / Repeater

Transceiver	Low power long-range LoRa
Frequency Band	915MHz
Communication Range	Up to 3km
Receiver Sensitivity	Down to -146dBm
TX Power	Up to +18dBm

Cloud Level Communication

Wired Network	Fast Ethernet (10/100)
Telemetry Protocol	MQTT v5.0 over TCP/IP

Encryption

Advanced Encryption Standard (AES)
Data Encryption Standard (DES)
Secure Hash Algorithm /Message Digest
Algorithm (SHA / MD5)
Cyclical Redundancy Check (CRC)

Pushbuttons	3 pushbuttons for gateway function
Status LED	4 status LED’s (red, green, amber)

FCC	2AXVKGTW01
Industry Canada	26661-GTW01
Safety Standards	UL Std. No. 61010-1 3rd Edition + Amd. 1:2018 CAN/CSA-C22.2 No. 61010-1-12 Third Edition + Amd. 1:2018

What It Does

Features

5

Gateway Features:

The GTW-BL100 includes sensors for ambient temperature, humidity, and tri-axis accelerometer to monitor environmental conditions and movement.

5

Connectivity & Communication:

It supports multiple connectivity options including LoRa 900MHz and secure communication protocols like AES 128-bit encryption over BLE and TCP/IP.

5

Microcontrollers & Processing:

Equipped with powerful 32-bit Arm Cortex-M4F MCUs, the GTW-BL100 ensures efficient wireless processing and communication.

5

Power & Circuit Protection:

The device features Power over Ethernet (PoE), multi-rail power management, and robust circuit protection against over-voltage, over-current, reverse polarity, and thermal shutdown.

5

User Interface & Display:

The GTW-BL100 features 3 pushbuttons for pairing functionality and powering the device on and off, offering a user-friendly interface for easy operation.
