Quad-Band Gateway
E4A's Quad Band Gateway is designed to meet the increasing demand for LTE connectivity in rural industrial sites, such as power generation utilities, mining, forestry, construction, and many others.
Many of these remote operations and facilities do not have corporate Local Area Network (LAN) coverage, which can hinder communication with remote wireless sensors.
By enabling LTE connectivity, E4A’s gateway ensures reliable communication between sensors at these sites and the central corporate network, facilitating seamless data transmission to the central repository.
Gateway Features
Includes sensors for ambient temperature, humidity, and tri-axis accelerometer to monitor environmental conditions and movement.
Connectivity & Communication
Multiple connectivity options including LTE Cat 1, LoRa 900MHz, Wi-Fi, and secure communication protocols like AES 128-bit encryption over BLE and TCP/IP.
Microcontrollers & Processing
Equipped with powerful 32-bit Arm Cortex-M4F MCUs, the GTW-200 ensures efficient wireless processing and communication.
Power & Circuit Protection
Features Power over Ethernet (PoE), multi-rail power management, and robust circuit protection against over-voltage, over-current, reverse polarity, and thermal shutdown.
User Interface & Display
Offers a variety of inputs and outputs including analog and digital ports, SD card slot, SIM card slot, and is designed for flexible wall and DIN rail mounting.
Special Features
Includes an internal memory card, QR code labeling for easy identification, and the ability to monitor operational data securely.
Technical Specification
| DC Input | 9 VDC to 12 VDC |
| DC Input Jack | 5.5 mm OD, 2.5 mm ID Centre Pin Positive |
| AC/DC Power Adapter | CUI Inc. SWI24-12-N-P6 |
| Power over Ethernet | PoE+, IEEE 802.3at, Mode A and B |
| USB-C | USB Type-C / USB 3.0 PD Sink, 15 W |
| Typical Power Consumption | 2.1 W (Bluetooth, LCD, Ethernet Active) |
| Ingress Protection Rating | IP30 |
| Pollution Degree | 2 |
| Operating Temperature | 0°C to +40°C (DC) 20°C to +60°C ((PoE+, USB-C) |
| Storage Temperature | -40°C to +85°C |
| Permissible Humidity | 20-85% (operating and storage) |
| Relay Outputs | Rated to switch resistive loads up to 2 A at 30 VDC, and 0.9 A at 60 VDC |
| Digital Inputs | Referenced to pin 7 on terminal block |
| Current Input | 4 mA to 20 mA current input |
| Analog Input | ± 10 VDC analog input |
| Resolution | 16-bit resolution |
| Temperature Measurement | -40ºC to +120ºC (±0.5ºC accuracy) |
| Humidity Measurement | 0-100% relative humidity (±3.5% RH accuracy) |
| Acceleration Measurement | 3-axis acceleration measured in milli-g |
| Housing Material | ABS plastic |
| Physical Dimensions | Height: 294 mm / 11.6 inches Width: 59.5 mm / 2.3 inches Depth: 170 mm / 6.7 inches |
| Weight | 550g |
| Mounting | Universal DIN rail 35mm width Magnetic mount (4 rear mounted magnets) |
Device Level Communication
| Wireless Module | 2.4GHz Bluetooth 5.0 transceiver LoRa 900MHz |
| Communication Range | 300m line of sight for Bluetooth |
| Communication Interval | User programmable |
| Output Power | Up to +5dBm with temp. compensation |
| Receiver Sensitivity | -105dBm, 125kbps |
Cloud Level Communication
| Wireless Module | 802.11b /g/n Wi-Fi Module EC21 LTE Cat 1 Module |
| Wired Network | PoE+, IEEE 802.3at, Mode A and B |
| Encryption | AES 128 symmetric encryption RSA 2048 encryption for key exchange |
User Interface
| OLED | Graphic LCD Display Module White OLED – I 2.7″ (68.58mm) 128 x 64 Pixel Resolution |
| Push Buttons | 6 Function Keys 7 keys for menu navigation |
| LED | 6 status LED |
System Interface
| USB-C | Gateway configuration |
| RS-232 | Custom serial communication integration |
| 10-Pin Terminal Header | Analog and Digital Inputs, Relay Outputs |
| SD Card | Firmware upgrade |
| SIM Card | Cloud communication over LTE |
| FCC | 2AXVKGTW02 |
| Industry Canada | 26661-GTW02 |
| Safety | CSA C22.2 No. 61010-1-12 UPD 1: Jul 2015, UPD 2: APR 2016, UPD 3: Jun 2023 and AMD 1:2018 CSA C22.2 No. 61010-2-030:18 UL 61010-1 3rd Edition:2023 UL 61010-2-030 Ed.2:2018 |
What It Does
Features
Gateway Features:
The GTW-200 includes sensors for ambient temperature, humidity, and tri-axis accelerometer to monitor environmental conditions and movement.
Connectivity & Communication:
It supports multiple connectivity options including LTE Cat 1, LoRa 900MHz, Wi-Fi, and secure communication protocols like AES 128-bit encryption over BLE and TCP/IP.
Microcontrollers & Processing:
Equipped with powerful 32-bit Arm Cortex-M4F MCUs, the GTW-200 ensures efficient wireless processing and communication.
Power & Circuit Protection:
The device features Power over Ethernet (PoE), multi-rail power management, and robust circuit protection against over-voltage, over-current, reverse polarity, and thermal shutdown.
User Interface & Display:
The GTW-200 features an OLED display, 7 pushbuttons for menu navigation, 6 function keys, and 6 LED indicators, offering a user-friendly interface for easy operation.
Inputs/Outputs & Mounting:
It offers a variety of inputs and outputs including analog and digital ports, SD card slot, SIM card slot, and is designed for flexible wall and DIN rail mounting.
Safety & Environmental Design:
The device ensures safe operation with an IP30 rating, customizable ventilation, and industrial-grade enclosure for durability.
Special Features:
It includes an internal memory card, QR code labeling for easy identification, and the ability to monitor operational data securely.
